TRILOGY 3 IN 1
COMPLETE TECHNICAL SUMMARY
Painless Diode Laser Hair Removal (SHR)
SHR Painless Triple Wavelength Diode Laser Hair Removal Machine for all skin types.
Three wavelengths, 808nm, 755nm, and 1064nm simultaneous release laser.
Built-in contact cooling. In motion technology & extra large spot size.
The -5° Celcius of 20° Fahrenheit Arctic sapphire crystal chill tip makes the treatment painless
Glide (IMT) in Motion Technology - Ful Body Treatment in One Hour - Ultra Fast
12x20mm spot size (large)
4cm2 spot size (extra large)
Trilogy Smart IPL
(IPL) Intense Pulsed Light, for epidermal photo-rejuvenation or photo-facial.
Effective for erasing mild sun damage, freckles, irregular pigmentation and light brown spots.
Treatments for face, neck, chest, back and whole body.
Photo Dynamic Therapy • Photo Facial • Photo Acne Therapy • Photo Vascular Therapy
Hyperpigmentation Therapy • Lip Plumping • Rosacea • Sun Damage
Pore Size Reduction • Skin Tightening • Erase Fine Wrinkles • Skin Tone Management
Q-Switched Laser Tattoo Removal
20-30% reduction of tattoo pigments per treatment
1064nm for black, dark blue, dark green
532nm for red, yellow, pink, permanent make-up including lip line
755nm for teal, light blue, light green (optional purchase)
1320 Skin rejuvenation, carbon blasting, skin tightening, collagen stimulation
TRILOGY DIODE LASER (SHR)
Painless Laser Hair Removal - 30 Million Pulses
Super Hair Removal (SHR): The primary principle behind diode laser hair removal is selective photo thermolysis (SPT). The matching of a specific wavelength of light, pulse duration, and photo energy to obtain optimal effect on a targeted tissue with minimal or no damaging effect on surrounding tissue. The diode lasers cause localized damage by selectively heating the melanin, thereby, heating up the basal stem cells in the follicle which causes hair growth. The -5° Celsius or 23° Fahrenheit degrees Arctic sapphire crystal built-in cooling tip provides comfort and a painless treatment.
3 wavelengths, 808nm, 755nm and 1064nm simultaneous release laser
-5 Celsius contact cooling tip Arctic Sapphire (built-in)
Glide (IMT) In Motion Technology – Fully Body Treatment in One Hour - Ultra Fast
12x20mm spot size (extra large)
TRILOGY SMART IPL
Photo Facial, Face Lift, Acne
(IPL) Intense Pulsed Light, also known as the principle technology for epidermal photo-rejuvenation or the photo-facial. Treatments are performed under Doctor's supervision and med-spas, day-spa and aesthetic establishments. IPL can be highly effective for erasing mild sun damage, freckles, irregular pigmentation and light brown spots on the face, neck, chest and back. IPL treats the skin with quick and powerful flashes of light, the light energy then penetrates below the skin’s surface, where the unwanted brown pigment (melanin) lives. The heat breaks down the pigment into tiny particles, which either rise to the skin’s surface or are flushed out by the body’s lymphatic system. This technology utilizes British Made Heavy Duty Cycle IPL Energy Source. Full Spectrum wavelengths for acne, 430nm - 1200nm high dose smart IPL.
(IPL) Intense Pulsed Light, for Epidermal Photo-Rejuvenation or Photo-Facial.
Erase Mild Sun Damage, Freckles, Irregular Pigmentation and Light Brown Spots.
Treatments for Face, Neck, Chest, Back, Décolletage & Full Body.
Photo Dynamic Therapy • Photo Facial • Photo Acne Therapy • Photo Vascular Therapy
Hyperpigmentation Therapy • Lip Plumping • Rosacea • Sun Damage
Pore Size Reduction • Skin Tightening • Fade Fine Wrinkles • Skin Tone Management
TRILOGY Q-SWITCH
Tattoo / Permanent Make-up / Birthmarks / Age spots Removal
Tattoos consist of thousands of particles of ink pigment suspended in the skin. While normal human growth and healing processes will remove small foreign particles from the skin and the body, tattoo pigment particles are permanent because they are too large to be removed naturally. Q-Switch ND: YAG laser treatment causes the tattoo pigment particles to heat up and fragment into smaller pieces. These smaller pieces are then removed by the lymphatic system.
20-30% reduction of tattoo pigments per treatment
1064nm for black, dark blue, dark green
532nm for red, yellow, pink, permanent make-up including lip line
755nm for teal, light blue, light green (optional purchase)
1320 Skin rejuvenation, carbon blasting, skin tightening, collagen stimulation
Certified Training
TRILOGY 3 in 1 is very easy to use, mostly it's point and shoot technology. Within 30 minutes you can get going. Comprehensive training is available. A snapshot of the training provided includes:
A snapshot of the training includes:
Dedicated Training
Certification or licensed training
Science & mechanisms of action for all three modalities
Operator and patient safety
General protocols
Device maintenance
Technique and procedures
Sequence of protocol
Parameters and pre-sets
General patient/operator communication
Basic marketing deployment
Patient communication
Furthermore, ongoing access and support is always available.
Support Included
Photo Biotech backs our products and customers. With a 3 year warranty and included comprehensive training and certification Photo Biotech extends further customer support with an extensive marketing kit professionally designed to illuminate the superior technological aspects and highlight the optimal results. The informative material will 'kick-start' and introduce this professional hardware for new and existing clientele.
Memory stick video loop demonstrating the treatment
Standing Banner
TriFold brochure to place the reception desk
4x6 post card for mail drop (direct marketing)
Content access: images and files
Print Media Kit
SPECIFICATIONS
| Model | TRILOGY 3 in 1 |
| SHOT COUNT | 30,000,000 PLUS HEAVY DUTY - NO CONSUMABLES |
| Software | Preset Parameters & Custom Set (DUAL) |
| Display system | 8.4-inch Color microcomputer touch screen |
| System | 808nm, 755nm, 1064nm Diode Laser & Q-Switch ND:YAG Laser & IPL |
| Laser Power | High Power Dedicated Power Board for Each Modality |
| TRIPLE Wavelength | 755nm 808nm, 1064nm ±0.5% simultaneous release in one handpiece |
| Power | 3000W, 4 Independent dedicated power boards |
| Diode laser Frequency | 1-10Hz |
| Diode laser energy | 160J/cm2(Optional) |
| Diode laser Pulse Duration | 5~ 650ms (Optional) |
| Diode laser Spot size | 12x22mm large default Available: 10*10 &12*12& 10*20 &15*27mm optional |
| Nd yag laser energy | 1-1600mJ |
| Nd yag laser frequency | 1-10HZ |
| Wavelength | 430/530/560/590/640-1200nm(standard) |
| Spot size | 15*50mm2 ;12*30mm2 /12*45mm2/8*40mm2 |
| IPL Light Energy | 10~50 J/cm2 (adjustable) |
| Pulse Duration | 2~15ms (adjustable) |
| Pulse number | 1~15 pulses (adjustable) |
| Delay Time | 5~50 ms (adjustable) |
| Integrated Skin Cooling | -4~10degree |
| Cooling system | Air & Close Water Circulation & Treatment head with semiconductor cooling temperature adjustable |
| Crystal temperature | -10~5°C |
| Power requirement | AC220V/110V 50~60Hz , 15amp breaker, no electrical modification required, |
| Languages | English |
